• Rated voltage: DC 16V
• Maximum poerating current: 0.3A
• Rotational life: 10000± cycles per below 100gf.cm
• Operating temperature range:-10°C~70°C
• Rotational torque: 10-70N (100-700gf)
• Insulation resistance: 500V DC 1min 100mw
• Dielectric strength: 500V AC 1minutes
|
 |
   |
| Part Number | Rated voltage | Maximum poerating current | Operating temperature range | Rotational torque | Insulation resistance | Dielectric strength | PDF下载 |
|---|---|---|---|---|---|---|---|
| RS17 | DC 16V | 0.3A | -10℃~70℃ | 10-70N (100-700gf) | 500V DC 1min 100mω | 500VAC 1 minutes | 暂无 |
